PLED96W-039
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DRIVER CV AC/DC 39V 2.45A
PDF
/
Inventory: 8355
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP66, NEMA 6
RoHS Status RoHS Compliant
Dimensions
Width 58.928mm
Length 150.114mm
Height 37.338mm
Technical
Topology AC DC Converter
Voltage - Output 39V
Current - Output (Max) 2.45A
Voltage - Input (Min) 90VAC
Max Output Current 2.45A
Voltage - Input (Max) 305VAC
Efficiency 89%
Approval Agency CE, cULus
Number of Outputs 1
Termination Style Wire Leads
Max Power Dissipation 96W
Power (Watts) 96W
Min Operating Temperature -30°C
Max Operating Temperature 65°C
Type Constant Voltage
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP
Size / Dimension 5.98Lx2.31W x 1.46 H 152.0mmx58.8mmx37.0mm
Series PLED96W
Published 2016
Operating Temperature -30°C~65°C
Physical
Weight 1.4lbs 635g
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 14 Weeks
