PLED75W-015-C5000-D
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DRIVER CC AC/DC 5-15V 5A
PDF
/
Inventory: 5154
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 1.2lbs 544.3g
Technical
Operating Temperature -30°C~65°C
Published 2016
Series PLED75W
Size / Dimension 5.00Lx2.32W x 1.47 H 140.2mmx58.9mmx37.3mm
Feature OCP, OVP, SCP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Type Constant Current
Power (Watts) 75W
Max Power Dissipation 75W
Termination Style Wire Leads
Number of Outputs 1
Approval Agency CE, cULus
Efficiency 86%
Voltage - Input (Max) 305VAC
Max Output Current 5A
Voltage - Input (Min) 90VAC
Voltage - Output 5V~15V
Topology AC DC Converter
Dimming Analog
Dimensions
Height 37.338mm
Compliance
RoHS Status RoHS Compliant
Ratings IP66, NEMA 6
