LED75W-064
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DRIVER CV AC/DC 64V 1.2A
PDF
/
Inventory: 6068
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Technical
Operating Temperature -30°C~70°C
Published 2016
Series LED-75W
Size / Dimension 6.42Lx2.81W x 1.83 H 173.0mmx71.3mmx46.5mm
Feature OCP, OVP, SCP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Type Constant Voltage
Max Operating Temperature 70°C
Min Operating Temperature -30°C
Power (Watts) 75W
Max Power Dissipation 75W
Termination Style Wire Leads
Number of Outputs 1
Approval Agency CE, cULus
Efficiency 90%
Voltage - Input (Max) 305VAC
Max Output Current 1.2A
Voltage - Input (Min) 90VAC
Current - Output (Max) 1.2A
Voltage - Output 64V
Topology AC DC Converter
Dimensions
Height 46.482mm
Length 163.068mm
Width 71.374mm
Compliance
RoHS Status RoHS Compliant
Ratings IP66
