LDC12-36-R35
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED CONSTANT CURRENT PS 36V 12W - More Details
PDF
/
Inventory: 8164
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 0.186lb 84.37g
Technical
Operating Temperature -10°C~60°C
Published 2009
Series LD12 (12W)
Size / Dimension 3.45Lx1.36W x 0.83 H 90.0mmx34.5mmx21.0mm
Feature OCP, OVP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Type Constant Current
Max Operating Temperature 60°C
Min Operating Temperature -10°C
Power (Watts) 13W
Power Rating 12W
Max Power Dissipation 13W
Depth 34.5mm
Termination Style Wire Leads
Number of Outputs 1
Approval Agency CE, IEC, UL
Efficiency 82%
Voltage - Isolation 3kV
Voltage - Input (Max) 264VAC
Max Output Current 350mA
Voltage - Output 1 36V
Voltage - Input (Min) 90VAC
Current - Output (Max) 350mA
Output Current 350mA
Output Power 12.6W
Voltage - Output 3V~36V
Topology AC DC Converter
Current - Output 1 350mA
Dimensions
Height 21.082mm
Length 87.63mm
Width 34.544mm
Compliance
RoHS Status RoHS Compliant
Ratings IP66
