ALD605012PS131
RoHS
/
Package 13-SMD Module
Category Power Supplies - Board Mount / LED Drivers
Description
TDK LAMBDA ALD605012PS131 LED DRIVER, DC-DC, 50mA, 38V
PDF
/
Buying Options
Total Price: USD $348.41
Unit Price: USD $348.4144
≥1 USD $348.4144
Inventory: 307
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 26.16mm
Length 8.8mm
Height 8.89mm
Technical
Dimming Analog, PWM
Nominal Input Voltage 12V
Current - Output 1 50mA
Max Input Voltage 13.2V
Min Input Voltage 10.8V
Topology Boost
Voltage - Output 12.8V~38V
Output Current 50mA
Current - Output (Max) 50mA
Voltage - Input (Min) 10.8V
Voltage - Output 1 38V
Max Output Current 50mA
Voltage - Input (Max) 13.2V
Number of Outputs 6
Max Power Dissipation 2W
Power (Watts) 2W
Min Operating Temperature -30°C
Max Operating Temperature 80°C
Type Constant Current
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Remote On/Off, OVP
Size / Dimension 0.90Lx0.83W x 0.35 H 22.9mmx21.1mmx8.8mm
Series ALD
Published 2010
Packaging Tray
Operating Temperature -30°C~80°C
Physical
Weight 0.012lb 5.44g
Package / Case 13-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 months ago)
Factory Lead Time 18 Weeks
Alternative Model
