STOOP2228B0Z032STD
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DRIVER CC AC/DC 28-36V 2.8A
PDF
/
Inventory: 1553
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP66
RoHS Status RoHS Compliant
Dimensions
Width 102.616mm
Length 258.064mm
Height 38.1mm
Technical
Dimming Analog
Max Input Voltage 240V
Min Input Voltage 220V
Topology AC DC Converter
Voltage - Output 28V~36V
Current - Output (Max) 2.8A
Voltage - Input (Min) 220VAC
Max Output Current 2.8A
Voltage - Input (Max) 240VAC
Efficiency 90%
Approval Agency CE
Number of Outputs 1
Termination Style Wire Leads
Max Power Dissipation 200W
Power (Watts) 200W
Min Operating Temperature -30°C
Max Operating Temperature 50°C
Type Constant Current
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OTP, OVP, SCP
Size / Dimension 10.16Lx4.04W x 1.50 H 258.0mmx102.6mmx38.0mm
Published 2014
Operating Temperature -30°C~50°C
Physical
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 6 Weeks
