RCD-24-1.20/W/X3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
RECOM POWER RCD-24-1.20/W/X3 LED Driver DC/DC Converter, RCD-24 Series, Panel, Analogue, Digital, PWM, 37.2 W, 31 V, 1.2 A
PDF
/
Buying Options
Total Price: USD $21.77
Unit Price: USD $21.768491
≥1 USD $21.768491
≥10 USD $20.53632
≥100 USD $19.373887
≥500 USD $18.277252
≥1000 USD $17.242682
Inventory: 1165
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Chassis Mount, Through Hole
Mounting Type Chassis Mount
Number of Pins 6
Weight 0.015lb 6.8g
Technical
Operating Temperature -40°C~65°C
Series LIGHTLINE RCD-24
Size / Dimension 0.87Lx0.49W x 0.33 H 22.1mmx12.6mmx8.5mm
Feature Remote On/Off, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
ECCN Code EAR99
Type Constant Current
Voltage - Rated 36V
Max Power Dissipation 37W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Termination Style Wire Leads
Number of Outputs 1
Approval Agency cULus
Efficiency 96%
Max Output Current 1.2A
Voltage - Output 1 33V
Voltage - Input (Min) 6V
Max Supply Voltage 36V
Min Supply Voltage 6V
Nominal Supply Current 1.2mA
Power Dissipation 800mW
Output Current 1.2A
Output Power 41W
Max Output Voltage 31V
Voltage - Output 3V~31V
Topology Buck
Current - Output 1 1.2A
Max Output Power 37W
Dimming Analog, PWM
Dimensions
Height 8.5mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings IP67
