RCD-24-0.50
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / LED Drivers
Description
0.5A LED-Driver 'LIGHTLINE' DIP reg; V. In: 4.5-36; V. Out: 2-35; mA. Out: 0-500
PDF
/
Buying Options
Total Price: USD $15.43
Unit Price: USD $15.4264
≥1 USD $15.4264
≥10 USD $14.65728
≥100 USD $13.8864
≥500 USD $13.50096
≥1000 USD $12.53648
≥3000 USD $11.95788
Inventory: 552
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height 8.5mm
Technical
Min Supply Voltage (DC) 4.5V
Max Supply Voltage (DC) 36V
Dimming Analog, PWM
Max Output Power 17.5W
Min Output Voltage 2V
Current - Output 1 500mA
Topology Buck
Voltage - Output 2V~35V
Max Output Voltage 35V
Output Power 17.5W
Output Current 500mA
Power Dissipation 800mW
Min Supply Voltage 4.5V
Max Supply Voltage 36V
Voltage - Output 1 35V
Max Output Current 500mA
Efficiency 96%
Approval Agency cULus
Qualification Status Not Qualified
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 500mA
Terminal Pitch 2.54mm
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Max Power Dissipation 18W
Subcategory Display Drivers
Type Constant Current
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 0.87Lx0.49W x 0.33 H 22.1mmx12.6mmx8.5mm
Series LIGHTLINE RCD-24
Packaging Tube
Operating Temperature -40°C~80°C
Physical
Weight 0.01lb 4.54g
Number of Pins 6
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 9 Weeks
