RACD20-350D-US
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DRIVER CC AC/DC 3-34V 350MA
PDF
/
Inventory: 6158
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP20
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 22.098mm
Technical
Current - Output 2 350mA
Dimming Analog
Max Output Power 20W
Current - Output 1 350mA
Topology AC DC Converter
Voltage - Output 2 34V
Voltage - Output 3V~34V
Output Power 20W
Output Current 350mA
Trim/Adjustable Output NO
Input Voltage-Nom 110V
Voltage - Input (Min) 90VAC
Voltage - Output 1 34V
Max Output Current 350mA
Voltage - Input (Max) 130VAC
Voltage - Isolation 3kV
Efficiency 80%
Approval Agency CE, EN, SEMKO, UL
Number of Outputs 2
Termination Style Terminal Block
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 50mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Technology HYBRID
Max Power Dissipation 20W
Voltage - Rated 264V
Type Constant Current
ECCN Code EAR99
Termination Terminal Block
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OCP, OTP, SCP
Size / Dimension 6.10Lx1.97W x 0.87 H 155.0mmx50.0mmx22.0mm
Series LIGHTLINE RACD20-D (20W)
Operating Temperature -20°C~40°C
Physical
Weight 0.309lb 140.16g
Package / Case Module
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
