RACD150-48-ENEC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DVR CC/CV AC/DC 34-48V 3.2A
PDF
/
Inventory: 3472
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP67
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 39.116mm
Technical
Current - Output 1 3.2A
Topology AC DC Converter
Voltage - Output 34V~48V
Output Power 150W
Output Current 3.2A
Voltage - Input (Min) 90VAC
Voltage - Output 1 48V
Max Output Current 3.2A
Voltage - Input (Max) 305VAC
Voltage - Isolation 3.75kV
Efficiency 90%
Approval Agency CE, ENEC
Number of Outputs 1
Termination Style Wire Leads
Max Power Dissipation 150W
Type Constant Current, Voltage
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OCP, OTP, OVP, SCP
Size / Dimension 8.74Lx2.68W x 1.54 H 222.0mmx68.0mmx39.0mm
Series LIGHTLINE RACD150-ENEC (150W)
Operating Temperature -30°C~70°C
Physical
Weight 2.4lbs 1.1kg
Mounting Type Chassis Mount
Mount Chassis Mount
