PLC-040S035
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED Drivers Power Supplies LED DRIVER 40W C/C .35A 95X70X32
PDF
/
Inventory: 7210
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP65
RoHS Status ROHS3 Compliant
Dimensions
Width 70.104mm
Length 94.996mm
Height 32.004mm
Technical
Current - Output 1 350mA
Topology AC DC Converter
Voltage - Output 38V~114V
Current - Output (Max) 350mA
Voltage - Input (Min) 90VAC
Voltage - Output 1 114V
Max Output Current 350mA
Voltage - Input (Max) 305VAC
Voltage - Isolation 2kV
Efficiency 88%
Approval Agency cULus
Number of Outputs 1
Termination Style Wire Leads
Max Power Dissipation 40W
Power (Watts) 40W
Min Operating Temperature -25°C
Max Operating Temperature 50°C
Type Constant Current
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OTP, OVP, SCP
Size / Dimension 3.74Lx2.76W x 1.26 H 95.0mmx70.0mmx32.0mm
Series PLC-040 (40W)
Published 2012
Operating Temperature -25°C~50°C
Physical
Mounting Type Chassis Mount
Mount Chassis Mount
Alternative Model
