PDA125W-1A4F
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED Drivers Power Supplies 125W 89.3V 1400mA CC LED Driver Dimming
PDF
/
Inventory: 5683
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP66
RoHS Status RoHS Compliant
Dimensions
Height 38.1mm
Technical
Dimming Analog
Current - Output 1 1.05A
Topology AC DC Converter
Voltage - Output 67V~89.3V
Voltage - Input (Min) 90VAC
Voltage - Output 1 119V
Max Output Current 1.4A
Voltage - Input (Max) 304VAC
Voltage - Isolation 4.242kV
Efficiency 93%
Approval Agency CE, cULus
Number of Outputs 1
Termination Style Wire Leads
Max Power Dissipation 125W
Power (Watts) 125W
Type Constant Current
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OCP, OVP, SCP
Size / Dimension 8.55Lx2.68W x 1.50 H 217.2mmx68.0mmx38.0mm
Series PDA (125W)
Published 2013
Operating Temperature -40°C~60°C
Physical
Weight 2.1lbs 952.5g
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 16 Weeks
