7023-D-E-700

LEDdynamics Inc.
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description LED DRIVER CC BUCK 32V 700MA
PDF
/
Inventory: 5708
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Chassis Mount
Mounting Type Chassis Mount

Technical

Operating Temperature -40°C~80°C
Published 2012
Series BuckPlus? 7023
Size / Dimension 0.83Lx0.83W x 0.43 H 21.1mmx21.1mmx10.9mm
Feature SCP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Type Constant Current
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Power (Watts) 22W
Max Power Dissipation 22W
Termination Style Wire Leads
Number of Outputs 1
Efficiency 95%
Voltage - Input (Max) 32V
Max Output Current 700mA
Voltage - Input (Min) 7V
Current - Output (Max) 700mA
Voltage - Output 32V Max
Topology Buck
Min Input Voltage 7V
Max Input Voltage 32V
Dimming Analog

Dimensions

Height 10.922mm
Length 21.082mm
Width 21.082mm

Compliance

RoHS Status Non-RoHS Compliant
