3023-D-E-700
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DRIVER CC BUCK 32V 700MA
PDF
/
Buying Options
Total Price: USD $12.31
Unit Price: USD $12.3112
≥1 USD $12.3112
≥10 USD $11.9504
≥100 USD $11.60727
Inventory: 123
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Module
Technical
Operating Temperature -40°C~80°C
Published 2012
Series BuckPuck? 3021/3023
Size / Dimension 0.83Lx0.83W x 0.43 H 21.0mmx21.0mmx11.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Type Constant Current
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Power (Watts) 22W
Max Power Dissipation 22W
Termination Style Wire Leads
Number of Outputs 1
Efficiency 95%
Voltage - Input (Max) 32V
Max Output Current 700mA
Voltage - Input (Min) 7V
Current - Output (Max) 700mA
Output Current 700mA
Voltage - Output 32V Max
Topology Buck
Min Input Voltage 7V
Max Input Voltage 32V
Dimming Analog
Dimensions
Height 10.922mm
Length 21.082mm
Width 21.082mm
Compliance
RoHS Status RoHS Compliant
