3023-D-E-500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DRIVER CC BUCK 32V 500MA
PDF
/
Buying Options
Total Price: USD $12.31
Unit Price: USD $12.3112
≥1 USD $12.3112
≥10 USD $11.9504
≥100 USD $11.60727
Inventory: 86
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 21.082mm
Length 21.082mm
Height 10.922mm
Technical
Dimming Analog
Max Input Voltage 32V
Min Input Voltage 7V
Topology Buck
Voltage - Output 32V Max
Current - Output (Max) 500mA
Voltage - Input (Min) 7V
Max Output Current 500mA
Voltage - Input (Max) 32V
Efficiency 95%
Number of Outputs 1
Termination Style Wire Leads
Max Power Dissipation 16W
Power (Watts) 16W
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Type Constant Current
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.83Lx0.83W x 0.43 H 21.0mmx21.0mmx11.0mm
Series BuckPuck? 3021/3023
Published 2013
Operating Temperature -40°C~80°C
Physical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
