LDB200-048SW
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / LED Drivers
Description
LED DVR CC/CV AC/DC 24-48V 4.25A
PDF
/
Inventory: 6854
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Chassis Mount
Weight 2.3lbs 1kg
Technical
Operating Temperature -30°C~70°C
Series LDB200 (200W)
Size / Dimension 8.78Lx2.48W x 1.38 H 223.0mmx63.0mmx35.0mm
Feature OCP, OTP, OVP, SCP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Constant Current, Voltage
Power (Watts) 200W
Termination Style Wire Leads
Number of Outputs 1
Approval Agency CE, CSA, cULus, EN
Efficiency 93.5%
Voltage - Isolation 3.75kV
Voltage - Input (Max) 305VAC
Voltage - Input (Min) 90VAC
Current - Output (Max) 4.25A
Voltage - Output 24V~48V
Topology AC DC Converter
Compliance
Ratings IP67
