1479795-9
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Keystone - Inserts
Description
Modular Connectors / Ethernet Connectors JACK SCTP REAR ENTRY SECURE
PDF
/
Inventory: 6311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Cat6
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Exterior Contact Finish Thickness 50μin 1.27μm
Plating Thickness 1.27μm
Technical
Exterior Contact Finish Gold
Exterior Housing Color Orange
Interior Type (Adapter End) IDC, Pressdown, Punchdown Block
Exterior Type (Adapter End) Modular Jack 8p8c (RJ45, Ethernet)
Keyed Yes
Direction User Selectable
Number of Ports 1
ELV Compliant
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Reach Compliance Code unknown
Style Modular
Orientation Straight
Total Number of Contacts 8
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Number of Positions 8
Connector Type TELECOM AND DATACOM CONNECTOR
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Shielded
JESD-609 Code e3
Series SL 110Connect
Published 2012
Operating Temperature -10°C~60°C
Physical
Exterior Contact Material Beryllium Copper
Exterior Housing Material Polycarbonate (PC)
Housing Material Polycarbonate
Shell Material POLYPHENYLENE OXIDE
Mount Panel
Contact Material Copper
Supply Chain
Factory Lead Time 3 Weeks
