86BC2-002
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keypad Switches
Description
Keypad 16 Key Terminal Pins 10mA 24VDC 3.43N
PDF
/
Inventory: 985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 68.58mm
Height 9.14mm
Technical
Legend Color Black
Key Color White
Operational Life 3,000,000 Cycles
Legend Type Fixed
Matrix (Columns x Rows) 4 x 4
Key Type Polymer
Number of Switches 16
Switch Action MOMENTARY
Actuator Travel 0.381 mm
Contact Function OFF-(ON)
Legend 0 ~ 9, A ~ F
Contact Rating @ Voltage 0.01A @ 24VDC
Contact (DC) Max Rating R Load 0.01A@24VDC
Contact Timing BREAK-BEFORE-MAKE
Operating Force 3.43 N
Switch Type Snap Dome
Illumination Non-Illuminated
Electrical Life 3000000 Cycle(s)
Dielectric Withstanding Voltage 250VAC V
Contact Current(DC)-Max 0.01A
Contact Resistance 10Ohm
Switch Function SPST
Output Type Common Bus
Actuator Type KEYPAD
Termination Style Pin Header
Depth 76.2mm
Ingress Protection IP40
HTS Code 8536.50.90.40
Terminal Finish TIN-LEAD
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 86
Published 2010
Operating Temperature -40°C~80°C
Physical
End Contact Plating GOLD
End Contact Material STAINLESS STEEL
Terminal Material PHOSPHOR BRONZE
Center Contact Material STAINLESS STEEL
Center Contact Plating GOLD
Actuator Material ACRYLONITRILE BUTADIENE STYRENE
Housing Material Polycarbonate
Mounting Type Panel Mount, Front or Rear
Mount Front, Panel
Supply Chain
Factory Lead Time 14 Weeks
