84LS-BB2-014
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keypad Switches
Description
Keypad;4 x 4;3.100 + 0.020 in.;1000 Megohms (Min.);Silicone Rubber;Matrix
PDF
/
Inventory: 6190
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.267 inch
Height 508μm
Technical
Legend Color White
Key Color Black
Operational Life 3,000,000 Cycles
Legend Type Fixed
Matrix (Columns x Rows) 4 x 4
Key Type Rubber Overlay
Number of Switches 16
Switch Action MOMENTARY
Legend Telephone Format, A ~ F
Contact Rating @ Voltage 0.01A @ 24VDC
Contact (DC) Max Rating R Load 0.01A@24VDC
Switch Type Snap Dome
Illumination Non-Illuminated
Electrical Life 3000000 Cycle(s)
Sealing EPOXY
Contact Current(DC)-Max 0.01A
Insulation Resistance 1GOhm
Switch Function SPST
Output Type Matrix
Actuator Type KEYPAD
Body Breadth 78.74 mm
Body Length or Diameter 78.74mm
Termination Style Pin Header
Current Rating 10mA
Ingress Protection IP67 - Dust Tight, Waterproof
Voltage - Rated DC 24V
HTS Code 8536.50.90.40
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Shielded
Series 84LS
Published 2007
Operating Temperature -55°C~85°C
Physical
Terminal Material COPPER ALLOY
Actuator Material Rubber, Silicone
Mounting Type Panel Mount, Front
Mount Front, Panel
Supply Chain
Factory Lead Time 14 Weeks
