84BLN-BB1-014A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keypad Switches
Description
KEYPAD 84BL Panel Mount Front Illuminated - Red Keypad Switch 0.762mm 0.1A 1.95VDC 0.01A @ 24VDC
PDF
/
Inventory: 6109
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP67, Waterproof
RoHS Status RoHS Compliant
Dimensions
Length - Termination 0.267 inch
Body Height 5.2578mm
Technical
Legend Color Translucent
Key Color Black
Operational Life 3,000,000 Cycles
Legend Type Fixed
Matrix (Columns x Rows) 4 x 4
Key Type Rubber Overlay
Number of Switches 16
Actuator Travel 0.762 mm
Legend Telephone Format, A ~ F
Contact Rating @ Voltage 0.01A @ 24VDC
Contact (DC) Max Rating R Load 0.1A@24VDC
Illumination Color Red
Switch Type Snap Dome
Illumination Illuminated - Red
Electrical Life 3000000 Cycle(s)
Sealing EPOXY
Illumination Voltage (Nominal) 1.95VDC
Contact Current(DC)-Max 0.1A
Insulation Resistance 1000000000Ohm
Switch Function SPST
Output Type Matrix
Actuator Type KEYPAD
Body Breadth 78.74 mm
Body Length or Diameter 78.74mm
Termination Style Pin Header
Ingress Protection IP67 - Dust Tight, Waterproof
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 84BL
Published 2007
Physical
Terminal Material COPPER ALLOY
Actuator Material SILICON RUBBER
Mounting Type Panel Mount, Front
Mount Front, Panel
Supply Chain
Factory Lead Time 14 Weeks
