LBW7K-2T5B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keylock Switches
Description
Flat Key LBW 2 Panel Mount Keylock Switch 34.90mm 5A AC/DC 125V 90°
PDF
/
Inventory: 3381
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Silver (Ag)
Mounting Type Panel Mount
Technical
Operating Temperature -25°C~60°C
Series LBW
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Positions 2
Voltage - Rated DC 30V
Current Rating (Amps) 5A AC/DC
Contact Finish Silver
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Actuator Type Flat Key
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Square - 22.50mm2
Electrical Life 50,000 Cycles
Mechanical Life 250,000 Cycles
Switch Type KEYLOCK SWITCH
Contact Timing Not Specified
Angle of Throw 90°
Depth Behind Flange 34.90mm
Key Removable Positions Left
Compliance
RoHS Status ROHS3 Compliant
