LBW6MK-3ST2A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keylock Switches
Description
Flat Key LBW 3 Panel Mount Keylock Switch 34.90mm 100mA AC/DC 125V 45°
PDF
/
Inventory: 4065
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Key Removable Positions All
Depth Behind Flange 34.90mm
Angle of Throw 45°
Contact Timing Not Specified
Switch Type KEYLOCK SWITCH
Mechanical Life 250,000 Cycles
Electrical Life 50,000 Cycles
Panel Cutout Dimensions Circular - 22.30mm Dia
Switch Function On-On-On
Circuit DPDT
Actuator Type Flat Key
Voltage - Rated AC 125V
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Contact Finish Gold
Current Rating (Amps) 100mA AC/DC
Voltage - Rated DC 30V
Number of Positions 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series LBW
Operating Temperature -25°C~60°C
Physical
Mounting Type Panel Mount
Contact Material Silver (Ag)
Supply Chain
Factory Lead Time 4 Weeks
