51-412.036D
RoHS
/
Package /
Category Switches / Keylock Switches
Description
Switch Key Lock N.O./N.C. DPST 90° Flat Key 0.1A 42VAC 42VDC Panel Mount
PDF
/
Buying Options
Total Price: USD $63.43
Unit Price: USD $63.4304
≥1 USD $63.4304
≥10 USD $57.79488
≥100 USD $53.918656
≥500 USD $51.804192
≥1000 USD $48.280056
Inventory: 96
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Key Removable Positions All
Depth Behind Flange 35.50mm
Angle of Throw 90°
Contact Timing Not Specified
Switch Type KEYLOCK SWITCH
Panel Cutout Dimensions Circular - 16.00mm Dia
Switch Function On-Off, Off-On
Circuit DPST-NO/NC
Actuator Type Flat Key
Voltage - Rated AC 42V
Termination Style PC Pin, Solder Lug
Current Rating (Amps) 100mA AC/DC
Number of Positions 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature IP65
Series 51
Operating Temperature -25°C~55°C
Physical
Mounting Type Panel Mount
Supply Chain
Factory Lead Time 8 Weeks
Alternative Model
