14-138.025K
RoHS
/
Package /
Category Switches / Keylock Switches
Description
KEYLOCK SWITCH 2 POSITIONS MAIN
PDF
/
Inventory: 4146
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Panel Mount
Technical
Operating Temperature -25°C~55°C
Series 14
Feature IP65
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Positions 2
Current Rating (Amps) 5A AC
Termination Style Solder Lug
Voltage - Rated AC 250V
Actuator Type Flat Key
Circuit 8PST-4NO/4NC
Switch Function On-Off, Off-On
Panel Cutout Dimensions Circular - 22.30mm Dia
Throw Configuration 4PDT
Mechanical Life 1,000,000 Cycles
Contact Current Rating 5A
Contact Timing Not Specified
Angle of Throw 90°
Depth Behind Flange 58.00mm
Key Removable Positions 1 only
Compliance
RoHS Status RoHS Compliant
