KO104B10001
RoHS
/
Package /
Category Switches / Keylock Switches
Description
SWITCH KEYLOCK 2POS SPDT 3A 125V
PDF
/
Inventory: 5608
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Panel
Mounting Type Panel Mount
Technical
Published 2001
Series KO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Number of Positions 2
Current Rating (Amps) 3A AC
Contact Finish Silver
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Tubular Key
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 16.00mm Dia
Contact Resistance 0.01mOhm
Dielectric Withstanding Voltage 1000VAC V
Switch Type KEYLOCK SWITCH
Contact Current(AC)-Max 1.5A
Contact Timing Not Specified
Index Angle 90 °
Depth Behind Flange 30.00mm
Key Removable Positions All
Bushing Diameter 0.63 inch
Bushing Type M16P1
Dimensions
Body Height 11.9888mm
Length - Termination 0.197 inch
Actuator Length 0.197 inch
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
