KO104A10004
RoHS
/
Package /
Category Switches / Keylock Switches
Description
Tubular Key KO 2 Panel Mount Keylock Switch 0.197inch 1.5A 1500VRMS V 90 °
PDF
/
Inventory: 6626
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 0.197 inch
Length - Termination 0.197 inch
Technical
Key Removable Positions 1 only
Depth Behind Flange 30.00mm
Index Angle 90 °
Contact Timing Not Specified
Contact Current(AC)-Max 1.5A
Switch Type KEYLOCK SWITCH
Dielectric Withstanding Voltage 1500VRMS V
Panel Cutout Dimensions Circular - 16.00mm Dia
Switch Function On-On
Circuit SPDT
Actuator Type Tubular Key
Voltage - Rated AC 125V
Termination Style Solder Lug
Contact Finish Silver
Current Rating 3A
Current Rating (Amps) 3A AC
Number of Positions 2
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series KO
Published 2008
Physical
Housing Material ZINC ALLOY
Mounting Type Panel Mount
Mount Panel
Contact Material Copper Alloy
