YF01132C203NQ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keylock Switches
Description
SWITCH KEYLOCK 2POS SPDT 4A 125V
PDF
/
Buying Options
Total Price: USD $20.94
Unit Price: USD $20.9352
≥1 USD $20.9352
≥10 USD $19.0168
≥100 USD $18.16173
≥500 USD $17.200207
≥1000 USD $16.559233
≥3000 USD $15.490895
Inventory: 459
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 17.78mm
Technical
Key Removable Positions 1 only
Depth Behind Flange 33.91mm
Index Angle 90 °
Contact Timing Not Specified
Contact Current Rating 4A
Max Voltage Rating (DC) 28V
Throw Configuration SPDT, SPST
Electrical Life 10,000 Cycles
Max Current Rating 4A
Panel Cutout Dimensions Circular - 11.99mm Dia
Switch Function On-On
Circuit SPDT
Actuator Type Flat Key
Voltage - Rated AC 125V
Termination Style Solder Lug
Contact Finish Silver
Current Rating 4A
Depth 15.88mm
Orientation Straight
Current Rating (Amps) 4A AC/DC
Voltage - Rated DC 28V
Number of Positions 2
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series YF
Published 2010
Physical
Housing Material Nylon
Mounting Type Panel Mount
Mount Panel
Contact Material Copper
Supply Chain
Factory Lead Time 20 Weeks
