Y2011U2C103LQ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keylock Switches
Description
SWITCH KEYLOCK 2POS DPDT 4A 125V
PDF
/
Buying Options
Total Price: USD $37.53
Unit Price: USD $37.530559
≥1 USD $37.530559
Inventory: 1666
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Key Removable Positions All
Depth Behind Flange 28.83mm
Angle of Throw 90°
Index Angle 90 °
Contact Timing Not Specified
Throw Configuration DPDT
Electrical Life 10,000 Cycles
Panel Cutout Dimensions Circular - 19.30mm Dia
Switch Function On-On
Circuit DPDT
Actuator Type Flat Key
Voltage - Rated AC 125V
Termination Style Solder Lug
Contact Finish Silver
Current Rating 4A
Current Rating (Amps) 4A AC/DC
Voltage - Rated DC 28V
Number of Positions 2
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Latch Pawl
Series Y
Published 2003
Physical
Mounting Type Panel Mount
Mount Panel
Contact Plating Silver
Contact Material Copper
Supply Chain
Factory Lead Time 10 Weeks
