P200AFTCM03Q22
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Keylock Switches
Description
Switch Key Lock DP3T 45° Flat Key 4A 250VAC Solder Lug Panel Mount
PDF
/
Buying Options
Total Price: USD $36.02
Unit Price: USD $36.018099
≥1 USD $36.018099
Inventory: 10010
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Housing Material Nylon
Technical
Published 2010
Series P
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 3
Current Rating (Amps) 4A AC
Orientation Straight
Depth 24.13mm
Current Rating 4A
Contact Finish Silver
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Flat Key
Circuit DP3T
Switch Function On-On-On
Panel Cutout Dimensions Circular - 20.30mm Dia
Max Voltage Rating (AC) 250V
Max Current Rating 4A
Electrical Life 10,000 Cycles
Contact Timing Not Specified
Index Angle 45 °
Depth Behind Flange 33.48mm
Key Removable Positions All
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
