H1011U2F205NQ
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Keylock Switches
Description
SW KEY 2POS SPDT 12A 125V 5PC
PDF
/
Buying Options
Total Price: USD $18.63
Unit Price: USD $18.6296
≥1 USD $18.6296
≥10 USD $16.9224
≥100 USD $16.7376
Inventory: 1104
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper
Mount Panel
Mounting Type Panel Mount
Package / Case 125
Housing Material Nylon
Technical
Operating Temperature -30°C~85°C
Published 2013
Series H
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Number of Positions 2
Voltage - Rated DC 125V
Current Rating (Amps) 12A AC 1A DC
Orientation Straight
Depth 22.35mm
Current Rating 1A
Contact Finish Silver
Termination Style Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Actuator Type Flat Key
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 19.30mm Dia
Max Voltage Rating (AC) 250V
Max Current Rating 12A
Electrical Life 10,000 Cycles
Throw Configuration SP, SP4T, SPDT
Max Voltage Rating (DC) 125V
Contact Current Rating 12A
Contact Timing Not Specified
Index Angle 90 °
Depth Behind Flange 36.61mm
Key Removable Positions All
Dimensions
Length 22.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
