SX0686/D
RoHS
/
Package /
Category Switches / Keylock Switches
Description
BULGIN SX0686/D Keylock Switch, DPDT-2NO / 2NC, Solder, 5 A, 250 V
PDF
/
Inventory: 1945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Key Removable Positions All
Depth Behind Flange 56.00mm
Angle of Throw 90°
Index Angle 90 °
Contact Timing Not Specified
Contact Current Rating 5A
Throw Configuration DPDT
Panel Cutout Dimensions Rectangular - 23.30mm x 21.30mm
Switch Function On-On
Circuit DPDT
Actuator Type Flat Key
Voltage - Rated AC 250V
Termination Style Solder Lug
Contact Finish Silver
Current Rating (Amps) 5A AC
Number of Positions 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series SX
Published 2007
Operating Temperature -20°C~70°C
Physical
Mounting Type Panel Mount
Contact Material Brass
