UCC5320ECD
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Isolators - Gate Drivers
Description
8-SOIC (0.154 3.90mm Width) 1 BUFFER OR INVERTER BASED PERIPHERAL DRIVER Capacitive Coupling Gate Driver 100kV/mus 3000Vrms 4.3A -40C~125C
PDF
/
Buying Options
Total Price: USD $2.4
Unit Price: USD $2.4024
≥1 USD $2.4024
≥10 USD $2.15512
≥100 USD $2.037842
≥500 USD $1.766098
Inventory: 322
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology Capacitive Coupling
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number UCC5320
Approval Agency CQC, CSA, UR, VDE
Voltage - Isolation 3000Vrms
Working Voltage 990V
Supply Voltage-Min (Vsup) 3V
Number of Channels 1
Current - Output High, Low 2.4A 2.2A
Rise / Fall Time (Typ) 12ns 10ns
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Propagation Delay tpLH / tpHL (Max) 72ns, 75ns
Common Mode Transient Immunity (Min) 100kV/μs
Supply Voltage1-Nom 15V
Built-in Protections TRANSIENT; UNDER VOLTAGE
Output Current Flow Direction SOURCE SINK
Pulse Width Distortion (Max) 20ns
Voltage - Output Supply 13.2V~33V
Current - Peak Output 4.3A
Supply Voltage1-Max 33V
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
RoHS Status ROHS3 Compliant
