TFDU6300-TR3
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Sensors, Transducers / IrDA Transceiver Modules
Description
TXRX IRDA 4MBIT 2.5MM SIDE 8-SMD
PDF
/
Buying Options
Total Price: USD $4.89
Unit Price: USD $4.8944
≥1 USD $4.8944
≥10 USD $4.01565
≥100 USD $3.89025
≥500 USD $3.76485
≥1000 USD $3.63945
Inventory: 6525
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SMD/SMT
Number of Pins 8
Technical
Operating Temperature -25°C~85°C
Packaging Tape & Reel (TR)
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 8
Terminal Finish Matte Tin (Sn)
Power Rating 500mW
Technology CMOS
Voltage - Supply 2.4V~3.6V
Terminal Position SINGLE
Orientation Side View
Terminal Form L BEND
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 8
Nominal Supply Current 2mA
Data Rate 4Mbs (FIR)
Size 8.5mmx3.1mmx2.5mm
Rise Time 40ns
Fall Time (Typ) 40 ns
Wavelength - Peak 886 nm
Interface IC Type INTERFACE CIRCUIT
Standards IrPHY 1.4
Idle Current, Typ @ 25°C 1.8mA
Link Range, Low Power 70cm
Dimensions
Height 3.1mm
Length 8.5mm
Width 2.5mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
