HSDL-3602-038
RoHS
/
Package SMD/SMT
Category Sensors, Transducers / IrDA Transceiver Modules
Description
TXRX IR 4MB/S 3V TOP VIEW SMD
PDF
/
Buying Options
Total Price: USD $5.39
Unit Price: USD $5.390767
≥1 USD $5.390767
≥200 USD $2.151843
≥500 USD $2.079634
≥1000 USD $2.044185
Inventory: 9558
Minimum: 1
-
+
Technical Details
Physical
Package / Case SMD/SMT
Surface Mount NO
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
Terminal Finish Tin (Sn)
Technology BICMOS
Voltage - Supply 2.7V~3.6V
Terminal Position SINGLE
Orientation Top View
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 10
JESD-30 Code R-XSMA-N10
Qualification Status Not Qualified
Data Rate 4Mbps
Size 12.2mmx4.9mmx4.0mm
Interface IC Type INTERFACE CIRCUIT
Standards IrDA 1.4
Idle Current, Typ @ 25°C 2.5mA
Link Range, Low Power 1.5m
Shutdown Yes
Compliance
RoHS Status RoHS Compliant
