HSDL-3203-021
RoHS
/
Package /
Category Sensors, Transducers / IrDA Transceiver Modules
Description
TXRX IR 115.2KB/S LOW POWER SMD
PDF
/
Buying Options
Total Price: USD $8.82
Unit Price: USD $8.816
≥1 USD $8.816
≥10 USD $7.23425
≥100 USD $7.00815
≥500 USD $6.78205
≥1000 USD $6.55595
Inventory: 17805
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Shutdown Yes
Link Range, Low Power 50cm
Idle Current, Typ @ 25°C 2.5mA
Standards IrDA 1.4
Interface IC Type INTERFACE CIRCUIT
Size 8.0mmx3.1mmx1.95mm
Data Rate 115.2kbps
Qualification Status Not Qualified
JESD-30 Code R-XSMA-N8
Pin Count 7
Time@Peak Reflow Temperature-Max (s) 10
Reach Compliance Code unknown
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Orientation Side View
Terminal Position SINGLE
Voltage - Supply 2.7V~3.6V
Technology BICMOS
Terminal Finish PURE TIN
Number of Terminations 8
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -20°C~70°C
Physical
Number of Pins 9
Surface Mount NO
