HSDL-3201#021
RoHS
/
Package SMD/SMT
Category Sensors, Transducers / IrDA Transceiver Modules
Description
TXRX IR 115.2KB/S 3V LOW PWR SMD
PDF
/
Buying Options
Total Price: USD $1.77
Unit Price: USD $1.76747
≥1 USD $1.76747
≥10 USD $1.66742
≥100 USD $1.57304
≥500 USD $1.484
≥1000 USD $1.4
≥3000 USD $1.32075
Inventory: 5226
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 2.5mm
Technical
Shutdown Yes
Link Range, Low Power 20cm
Idle Current, Typ @ 25°C 100μA
Standards IrDA 1.2
Wavelength 880 nm
Interface IC Type INTERFACE CIRCUIT
Size 7.5mmx3.35mmx2.8mm
Data Rate 115.2kbps
Operating Supply Voltage 2.6V
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 10
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Orientation Side View
Terminal Position SINGLE
Voltage - Supply 2.7V~3.6V
Technology BICMOS
Terminal Finish Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -25°C~85°C
Physical
Number of Pins 8
Package / Case SMD/SMT
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
