TL16C550CIPTR
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Interface - UARTs (Universal Asynchronous Receiver Transmitter)
Description
Tape & Reel (TR) EAR99 ALSO OPERATES AT 3.3V SUPPLY AT 14.9MHZ 0.125MBps interface UART 8mA -40C 7mm 16MHz
PDF
/
Buying Options
Total Price: USD $4.71
Unit Price: USD $4.708
≥1 USD $4.708
≥10 USD $4.23192
≥100 USD $4.00048
≥500 USD $3.466936
≥1000 USD $3.289194
≥3000 USD $2.951379
Inventory: 1334
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.4mm
Width 7mm
Length 7mm
Height 1.6mm
Technical
With Modem Control Yes
FIFO's 16 Byte
Data Encoding/Decoding Method NRZ
Communication Protocol ASYNC, BIT
Data Transfer Rate-Max 0.125 MBps
Number of Serial I/Os 1
Data Rate (Max) 1Mbps
Low Power Mode NO
Boundary Scan NO
Clock Frequency 16MHz
uPs/uCs/Peripheral ICs Type SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
Max Supply Current 8mA
Nominal Supply Current 8mA
Number of Channels 1, UART
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Pin Count 48
Base Part Number TL16C550
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 3V~5.25V
Technology CMOS
Subcategory Serial IO/Communication Controllers
HTS Code 8542.39.00.01
Additional Feature ALSO OPERATES AT 3.3V SUPPLY AT 14.9 MHZ
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 181.692094mg
Number of Pins 48
Package / Case 48-LQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
