TL16C550CFNRG4
RoHS
RoHS compliant
RoHS compliantPackage 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Interface - UARTs (Universal Asynchronous Receiver Transmitter)
Description
IC ASYNC COMM ELEMENT 44-PLCC
PDF
/
Buying Options
Total Price: USD $32.22
Unit Price: USD $32.21735
≥1 USD $32.21735
≥10 USD $26.43565
≥100 USD $25.60915
≥500 USD $24.78265
≥1000 USD $23.9571
Inventory: 859
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-LCC (J-Lead)
Number of Pins 44
Weight 2.265694g
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature ALSO OPERATES AT 3.3V SUPPLY AT 14.9 MHZ
HTS Code 8542.39.00.01
Subcategory Serial IO/Communication Controllers
Technology CMOS
Terminal Form J BEND
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 1.27mm
Base Part Number TL16C550
Pin Count 44
Operating Supply Voltage 5V
Temperature Grade COMMERCIAL
Number of Channels 1, UART
Nominal Supply Current 8mA
Max Supply Current 10mA
uPs/uCs/Peripheral ICs Type SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
Clock Frequency 16MHz
Boundary Scan NO
Low Power Mode NO
Data Rate (Max) 1Mbps
Number of Serial I/Os 1
Data Transfer Rate-Max 0.125 MBps
Communication Protocol ASYNC, BIT
Data Encoding/Decoding Method NRZ
FIFO's 16 Byte
With Modem Control Yes
Terminal Position QUAD
Voltage - Supply 3V~5.25V
Dimensions
Height 4.57mm
Length 16.59mm
Width 16.59mm
Thickness 4.06mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
