SC16C852LIB,128
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Interface - UARTs (Universal Asynchronous Receiver Transmitter)
Description
Tape & Reel (TR) S-PQFP-G48 0.625MBps 2010 interface UART 85C 7mm 80MHz 128Byte
PDF
/
Inventory: 8241
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 48-LQFP
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Published 2010
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Terminal Finish Matte Tin (Sn)
HTS Code 8542.31.00.01
Subcategory Serial IO/Communication Controllers
Technology CMOS
Voltage - Supply 1.8V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number SC16C852
Pin Count 48
JESD-30 Code S-PQFP-G48
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Supplies 1.8V
Temperature Grade INDUSTRIAL
Number of Channels 2, DUART
uPs/uCs/Peripheral ICs Type SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
Clock Frequency 80MHz
Address Bus Width 3
Protocol RS485
Boundary Scan NO
Low Power Mode YES
External Data Bus Width 8
Data Rate (Max) 5Mbps
Number of Serial I/Os 2
Data Transfer Rate-Max 0.625 MBps
Data Encoding/Decoding Method NRZ
FIFO's 128 Byte
With False Start Bit Detection Yes
Dimensions
Height Seated (Max) 1.6mm
Length 7mm
Width 7mm
Compliance
RoHS Status ROHS3 Compliant
