SC26C92A1B
RoHS
/
Package PQFP
Category Integrated Circuits (ICs) / Interface - UARTs (Universal Asynchronous Receiver Transmitter)
Description
Bulk EAR99 Tin (Sn) ASYNC BIT interface UART 10mA -40C 10mm 8MHz
PDF
/
Buying Options
Total Price: USD $77.86
Unit Price: USD $77.85915
≥1 USD $77.85915
≥10 USD $63.88465
≥100 USD $61.88775
≥500 USD $59.8918
≥1000 USD $57.89585
Inventory: 101
Minimum: 1
-
+
Technical Details
Technical
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 3
Number of Terminations 44
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Serial IO/Communication Controllers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.8mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 44
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Number of Channels 2
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Nominal Supply Current 10mA
uPs/uCs/Peripheral ICs Type SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
Clock Frequency 8MHz
Data Rate 230.4 kbps
Address Bus Width 4
Boundary Scan NO
Low Power Mode YES
External Data Bus Width 8
Packaging Bulk
Number of Serial I/Os 2
Communication Protocol ASYNC, BIT
Data Encoding/Decoding Method NRZ
Physical
Surface Mount YES
Package / Case PQFP
Dimensions
Length 10mm
Width 10mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
