DS26303LN-75+A3
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP Exposed Pad
Category Integrated Circuits (ICs) / Interface - Telecom
Description
ROHS3Compliant QUAD GULL WING Obsolete Telecom IC Line Interface Unit (LIU) -40C~85C 2.048MHz 20mm 1.65W
PDF
/
Inventory: 1144
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 144-LQFP Exposed Pad
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2007
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 144
Max Power Dissipation 1.65W
Voltage - Supply 3.135V~3.465V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DS26303
JESD-30 Code S-PQFP-G144
Function Line Interface Unit (LIU)
Operating Supply Voltage 3.465V
Interface LIU
Number of Circuits 8
Nominal Supply Current 478mA
Current - Supply 250mA
Max Frequency 2.048MHz
Telecom IC Type PCM TRANSCEIVER
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
RoHS Status ROHS3 Compliant
