CMX683E4
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Telecom
Description
e3 Parallel 16-TSSOP (0.173 4.40mm Width) TONE DECODER CIRCUIT interface telecom 2.7V~5.5V 1.5mA 300mW 4.4mm
PDF
/
Buying Options
Total Price: USD $6.99
Unit Price: USD $6.9872
≥1 USD $6.9872
≥10 USD $5.5792
≥100 USD $4.752
≥500 USD $3.894
Inventory: 263
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish Matte Tin (Sn)
Power (Watts) 300mW
Subcategory Telecom Signaling Circuits
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Function Tone Detector
Qualification Status Not Qualified
Power Supplies 3/5V
Interface Parallel
Number of Circuits 1
Current - Supply 1.5mA
Telecom IC Type TONE DECODER CIRCUIT
Dimensions
Length 5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
