TPS2371DR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Specialized
Description
IC PWR INTRFCE SW FOR POE 8-SOIC
PDF
/
Buying Options
Total Price: USD $4.3
Unit Price: USD $4.2959
≥1 USD $4.2959
≥10 USD $3.52545
≥100 USD $3.41525
≥500 USD $3.30505
≥1000 USD $3.19485
Inventory: 106
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Weight 72.603129mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Applications Power Interface Switch for Power Over Ethernet (PoE) Devices
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 48V
Terminal Pitch 1.27mm
Base Part Number TPS2371
Pin Count 8
Temperature Grade COMMERCIAL
Interface IEEE 802.3af
Telecom IC Type SUPPORT CIRCUIT
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
