TMDS341APFC
RoHS
RoHS compliant
RoHS compliantPackage 80-TQFP
Category Integrated Circuits (ICs) / Interface - Specialized
Description
IC INTERFACE SPECIALIZED 80TQFP
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.489
≥1 USD $2.489
≥10 USD $2.0425
≥100 USD $1.97885
≥500 USD $1.91425
≥1000 USD $1.8506
Inventory: 4009
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 80-TQFP
Number of Pins 80
Weight 373.590016mg
Technical
Packaging Tray
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 80
Termination SMD/SMT
Resistance 50Ohm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Applications 3:1 Switchable DVI/HDMI Receiver
HTS Code 8542.39.00.01
Max Power Dissipation 1.342W
Voltage - Supply 3V~3.6V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 100kHz
Base Part Number TMDS341
Output SEPARATE OUTPUT
Pin Count 80
Supply Voltage-Max (Vsup) 3.6V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 3V
Number of Channels 3
Interface DVI, HDMI
Analog IC - Other Type AUDIO/VIDEO SWITCH
Nominal Supply Current 190mA
Power Dissipation 1.342W
Propagation Delay 2 ns
Input Voltage (Max) 5.5V
Supply Current-Max (Isup) 230mA
Dimensions
Height 1.2mm
Length 12mm
Width 12mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
