PCA9546APWR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Interface - Specialized
Description
IC I2C SMBUS SWITCH 4CH 16-TSSOP
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.452
≥1 USD $1.452
≥10 USD $1.30328
≥100 USD $1.229536
≥500 USD $1.047552
≥1000 USD $0.983629
≥3000 USD $0.860658
Inventory: 1581
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 16
Weight 61.887009mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Resistance 16Ohm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications Translating Switch
Packing Method TR
Max Power Dissipation 400mW
Voltage - Supply 2.3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 2.5V
Base Part Number CA9546
Pin Count 16
Number of Outputs 1
Supply Voltage-Max (Vsup) 5.5V
Temperature Grade INDUSTRIAL
Supply Voltage-Min (Vsup) 2.3V
Interface I2C, SMBus
Operating Supply Current 8μA
Load Capacitance 50pF
Power Dissipation 400mW
Throw Configuration 4PST
Propagation Delay 1 ns
Quiescent Current 3μA
Logic Function Multiplexer
Number of Inputs 4
Bandwidth 400 kHz
Output Polarity TRUE
Max Frequency 400kHz
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
