PCA9518DBQR
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Interface - Specialized
Description
IC EXPANDABLE 5CH I2C HUB 20QSOP
PDF
/
Buying Options
Total Price: USD $18.77
Unit Price: USD $18.7739
≥1 USD $18.7739
≥10 USD $15.40425
≥100 USD $14.92355
≥500 USD $14.4419
≥1000 USD $13.96025
≥1000 USD $12.51625
Inventory: 1226
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mounting Type Surface Mount
Package / Case 20-SSOP (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 20
Weight 125.786834mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications Buffer
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number CA9518
Pin Count 20
Qualification Status Not Qualified
Operating Supply Voltage 3.6V
Temperature Grade INDUSTRIAL
Interface I2C
Number of I/O 5
Max Frequency 400kHz
Dimensions
Height 1.75mm
Length 8.65mm
Width 3.9mm
Thickness 1.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
