DS90CF363BMT/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Interface - Specialized
Description
IC INTERFACE SPECIALIZED 48TSSOP
PDF
/
Buying Options
Total Price: USD $3.41
Unit Price: USD $3.4056
≥1 USD $3.4056
≥10 USD $3.06152
≥100 USD $2.894505
≥500 USD $2.508616
≥1000 USD $2.379969
≥3000 USD $2.264909
Inventory: 1761
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-TFSOP (0.240, 6.10mm Width)
Number of Pins 48
Technical
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 48
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 70°C
Min Operating Temperature -10°C
Subcategory Line Driver or Receivers
Max Power Dissipation 1.98W
Technology CMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 3
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Base Part Number DS90CF363
Pin Count 48
Operating Supply Voltage 3.3V
Temperature Grade COMMERCIAL
Power Dissipation 1.98W
Max Supply Current 55mA
Data Rate 455 Mbps
Output Characteristics DIFFERENTIAL
Differential Output YES
Output Polarity COMPLEMENTARY
Input Characteristics STANDARD
Interface IC Type LINE DRIVER
Interface Standard EIA-644; TIA-644
Number of Drivers 3
Supply Voltage1-Nom 3.3V
Number of Receivers 21
Dimensions
Height 1.2mm
Length 12.5mm
Width 6.1mm
Thickness 1.15mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
