USB2240I-AEZG-06

Microchip Technology
RoHS
RoHS RoHS compliant
Package 36-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Interface - Specialized
Description IC INTERFACE SPECIALIZED 36QFN
PDF
/
Buying Options
Total Price: USD $3.12
Unit Price: USD $3.124
≥1 USD $3.124
≥10 USD $2.596
≥100 USD $2.3584
Inventory: 289
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-VFQFN Exposed Pad
Number of Pins 36

Technical

Packaging Tray
Published 2010
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications Controller
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number USB2240
Pin Count 36
Qualification Status Not Qualified
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Temperature Grade INDUSTRIAL
Interface Serial
Operating Supply Current 135mA
Data Rate 480 Mbps
Number of Transceivers 1

Dimensions

Height 950μm
Length 6.15mm
Width 6.15mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
