IXDP631PI
RoHS
/
Package 18-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Interface - Specialized
Description
IC GENERATOR DGTL DEADTIME 8DIP
PDF
/
Buying Options
Total Price: USD $21.19
Unit Price: USD $21.1911
≥1 USD $21.1911
≥10 USD $19.9916
≥100 USD $18.86
≥500 USD $17.79245
≥1000 USD $16.78533
≥3000 USD $15.83522
Inventory: 3000
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 7.62mm
Length 23.11mm
Technical
Max Supply Current 5mA
Output Current 25mA
Nominal Supply Current 5A
Analog IC - Other Type ANALOG CIRCUIT
Interface Microprocessor
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade INDUSTRIAL
Power Supplies 5V
Operating Supply Voltage 5.5V
Output Voltage 6V
Qualification Status Not Qualified
Number of Outputs 3
Pin Count 18
Base Part Number IXDP631
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 6.35mm
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Subcategory Other Analog ICs
Applications PWM Motor Controller
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 1998
Packaging Tube
Physical
Number of Pins 18
Package / Case 18-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
