UCC5618DWP
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - Signal Terminators
Description
Contains Lead Obsolete BICMOS GULL WING SCSI Terminator 0C~70C 110Ohm 440mA 2.35mm
PDF
/
Buying Options
Total Price: USD $4.19
Unit Price: USD $4.19235
≥1 USD $4.19235
≥10 USD $3.43995
≥100 USD $3.3326
≥500 USD $3.22525
≥1000 USD $3.1179
Inventory: 2788
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Weight 792.000628mg
Technical
Operating Temperature 0°C~70°C
Packaging Tube
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 18
ECCN Code EAR99
Type SCSI
Resistance 110Ohm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Bus Terminators
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 4.75V
Base Part Number UCC5618
Pin Count 28
Power Supplies 4.75V
Max Supply Voltage 5.25V
Min Supply Voltage 4V
Operating Supply Current 420mA
Nominal Supply Current 440mA
Differential Output NO
Number of Drivers 1
Number of Signal Lines 18
Pull-up Resistance-Nom 110Ohm
Dimensions
Height 2.35mm
Length 18mm
Width 7.52mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
